Technical Specification
| Interface |
USB3.0/CameraLink |
| Resolution |
320(H)x256(V) |
| Sensor format |
1/1.6 inch |
| Pixel pitch |
25µm |
| Mode |
Snapshot |
| Exposure time |
100us to 200ms |
| Spectral response |
0.9 to 1.7um |
| Dynamic range |
120dB |
| ADC |
14 bits |
| Frame rate |
Up to 200Hz |
| Trigger |
IN/OUT (LVTTL) |
| Power Consumption |
< 1.1W |
| Power Range |
5 to 12V |
| Dimension |
48.6x48.6x43.4mm |
| Mount |
CS/C |
| Weight |
<125g |
| Temperature Range |
-40 to 70°C |
| Mechanical |
Vibration and shock tested |
Software
| Interface |
GUI |
SDK |
| USB 3.0 |
NITVision |
Yes |
| CameraLink (Compact) |
WiDyCAM |
No |
Applications
With an attractive price, the WiDy SWIR 320 offers a sufficient QVGA resolution and image quality. This SWIR camera is valuable for some light flux environments, such as outdoor or industrial applications.
